| Specifications | |
| Product Attribute | Attribute Value |
| Product name | Eaton Moeller series xEffect - FAZ-NA, FAZ-RT MCB |
| Part no. | FAZ-D40/3-NA |
| Product Length/Depth | 105 millimetre |
| Product height | 75.5 millimetre |
| Product width | 53.1 millimetre |
| Product weight | 0.382 kilogram |
| Compliances | RoHS conform |
| Application | Feeder circuits, branch circuits Switchgear for export to North America (UL-listed) |
| Number of poles | Three-pole |
| Number of poles (total) | 3 |
| Number of poles (protected) | 3 |
| Amperage Rating | 40 A |
| Voltage type | AC |
| Voltage rating | 240 V AC |
| Voltage rating at DC | 60 V DC |
| Frequency rating - min | 50 Hz |
| Frequency rating - max | 60 Hz |
| Width in number of modular spacings | 3 |
| Built-in depth | 70.5 mm |
| Mounting width | 17.7 mm |
| Mounting width per pole | 17.7 mm |
| Ambient operating temperature - min | -25 °C |
| Ambient operating temperature - max | 75 °C |
